BRTIRPZ3013A
Precision Engineered Robotic Systems
FOUR AXIS SYSTEM DESIGN
“Four axis Industrial Robot for Palletizing Loading and Unloading | 130kg Load 3020mm Arm Length”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
130kg
Arm Length
3020mm
Repeated Positioning accuracy
±0.15mm
Weight
about 1200kg
Protection grade
Ip40
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Four-Axis Product Parameters
ModelBRTIRPZ3013A
Range(Arm)J1:±160° J2:-75°/+30° J3:-55°/+60°
Range(Wrist)J4:±180° R34:65°-185°
Max.speed(Arm)J1:63.8°/s J2:53°/s J3:53°/s
Max.speed(Wrist)J4:200°/s
Arm Length3020mm
Loading ability130kg
Repeated positioning accuracy±0.15mm
Power source8.23kVA
WeightAbout 1200kg
Application scenariosHandling ，Stacking ，Stamping ，Injection molding ， Assembling，etc.
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
