BRTIRUS0707A
Precision Engineered Robotic Systems
SIX AXIS SYSTEM DESIGN
“Six axis Industrial Robot for Flexible Production | 7kg Load 700mm Arm Length Multi Scenario Versatility Welding Polishing Assembling More”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
7kg
Arm Length
700mm
Repeated Positioning accuracy
±0.03mm
Weight
about 55kg
Protection grade
Ip65,Dust-proof and water-proof
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Six-Axis Product Parameters
ModelBRTIRUS0707A
Range(Arm)J1:±174° J2:-125°/+85° J3:-60°/+175°
Range(Wrist)J4:±180° J5:±120° J6:±360°
Max.speed(Arm)J1:220.8°/s J2:270°/s J3:375°/s
Max.speed(Wrist)J4:308°/s J5:300°/s J6:342°/s
Arm Length700mm
Loading ability7kg
Repeated positioning accuracy±0.03mm
Power source2.93kVA
WeightAbout 55kg
Application scenariosHandling, stamping, injection molding, grinding, cutting, deburring, gluing, palletizing, spraying, etc
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
