BRTIRWD1506A
Precision Engineered Robotic Systems
SIX AXIS SYSTEM DESIGN
“Six axis Industrial Robot for Welding | 6kg Load 1600mm Arm Length”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
6kg
Arm Length
1600mm
Repeated Positioning accuracy
±0.05mm
Weight
about 166kg
Protection grade
Ip54,Dust-proof and water-proof
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Six-Axis Product Parameters
ModelBRTIRWD1506A
Range(Arm)J1:±165° J2:-100°/+70° J3:±80°
Range(Wrist)J4:±150° J5:±110° J6:±360°
Max.speed(Arm)J1:163°/s J2:149°/s J3:223°/s
Max.speed(Wrist)J4:169°/s J5:270°/s J6:398°/s
Arm Length1600mm
Loading ability6kg
Repeated positioning accuracy±0.05mm
Power source4.64kVA
WeightAbout 166kg
Application scenariosHandling，Stamping，Injection molding，Grinding，Cutting，Deburring， Gluing，Stacking，Spraying, etc.
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
