BRTIRUS0805A
Precision Engineered Robotic Systems
SIX AXIS SYSTEM DESIGN
“Six axis Industrial Robot for Flexible Production | 5kg Load 940mm Arm Length Multi Scenario Versatility Welding Assembly Palletizing More”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
5kg
Arm Length
940mm
Repeated Positioning accuracy
±0.05mm
Weight
about 53kg
Protection grade
IP54 at the wrist and IP40 at the body
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Six-Axis Product Parameters
ModelBRTIRUS0805A
Range(Arm)J1:±170° J2:-98°/+80° J3:-80°/+95°
Range(Wrist)J4:±180° J5:±120° J6:±360°
Max.speed(Arm)J1:237°/s J2:267°/s J3:370°/s
Max.speed(Wrist)J4:337°/s J5:600°/s J6:588°/s
Arm Length940mm
Loading ability5kg
Repeated positioning accuracy±0.05mm
Power source3.67kVA
WeightAbout 53kg
Application scenariosHandling, stamping, injection molding, grinding, cutting, deburring, gluing, palletizing, spraying, etc
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
