BRTIRUS1820A
Precision Engineered Robotic Systems
SIX AXIS SYSTEM DESIGN
“Six axis Industrial Robot for Flexible Production | 20kg Load 1850mm Arm Length Multi Scenario Versatility Welding loading and unloading Palletizing More”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
20kg
Arm Length
1850mm
Repeated Positioning accuracy
±0.05mm
Weight
about 230kg
Protection grade
IP54 at the wrist and IP40 at the body
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Six-Axis Product Parameters
ModelBRTIRUS1820A
Range(Arm)J1:±155° J2:-140°/+65° J3:-75°/+110°
Range(Wrist)J4:±180° J5:±115° J6:±360°
Max.speed(Arm)J1:110.2°/s J2:140.5°/s J3:133.9°/s
Max.speed(Wrist)J4:272.7°/s J5:240°/s J6:375°/s
Arm Length1850mm
Loading ability20kg
Repeated positioning accuracy±0.05mm
Power source5.87kVA
WeightAbout 230kg
Application scenariosHandling，Stamping，Injection molding，Grinding，Cutting，Deburring， Gluing，Stacking，Spraying, etc.
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
