BRTIRUS2030A

Precision Engineered Robotic Systems
Payload Capacity
30kg
Working Reach
2058mm
Repeated Accuracy
±0.08mm
BRTIRUS2030A Front View
BRTIRUS2030A Side View
SIX AXIS SYSTEM DESIGN

“Six axis Industrial Robot for Flexible Production | 30kg Load 2058mm Arm Length Multi Scenario Versatility Welding Injection Molding Palletizing More”

System Specifications

Control System
HC Control System
Color(General)
red
Loading Ability
30kg
Arm Length
2058mm
Repeated Positioning accuracy
±0.08mm
Weight
about 310kg
Protection grade
IP54 at the wrist and IP40 at the body
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa

Six-Axis Product Parameters

ModelBRTIRUS2030A
Range(Arm)J1:±150° J2:-90°/+70° J3:-55°/+105°
Range(Wrist)J4:±180° J5:±115° J6:±360°
Max.speed(Arm)J1:102°/s J2:103°/s J3:123°/s
Max.speed(Wrist)J4:245°/s J5:270°/s J6:337°/s
Arm Length2058mm
Loading ability30kg
Repeated positioning accuracy±0.08mm
Power source6.11kVA
WeightAbout 310kg
Application scenariosHandling，Stamping，Injection molding，Grinding，Cutting，Deburring， Gluing，Stacking，Spraying, etc.
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
