BRTIRUS2110A
Precision Engineered Robotic Systems
SIX AXIS SYSTEM DESIGN
“Six axis Industrial Robot for Flexible Production | 10kg Load 2100mm Arm Length Multi Scenario Versatility Welding Stamping Palletizing More”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
10kg
Arm Length
2100mm
Repeated Positioning accuracy
±0.05mm
Weight
about 230kg
Protection grade
IP54 at the wrist and IP40 at the body
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Six-Axis Product Parameters
ModelBRTIRUS2110A
Range(Arm)J1:±155° J2:-90°（-140°，The descent is adjustable）/+65° J3:-75°/+110°
Range(Wrist)J4:±180° J5:±110° J6:±360°
Max.speed(Arm)J1:110°/s J2:146°/s J3:134°/s
Max.speed(Wrist)J4:273°/s J5:300°/s J6:336°/s
Arm Length2100mm
Loading ability10kg
Repeated positioning accuracy±0.05mm
Power source6.48kVA
WeightAbout 230kg
Application scenariosHandling，Stamping，Injection molding，Grinding，Cutting，Deburring， Gluing，Stacking，Spraying, etc.
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
