BRTIRUS2550A
Precision Engineered Robotic Systems
SIX AXIS SYSTEM DESIGN
“Six axis Industrial Robot for Flexible Production | 50kg Load 2550mm Arm Length Multi Scenario Versatility Welding Molding Palletizing More”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
50kg
Arm Length
2550mm
Repeated Positioning accuracy
±0.1mm
Weight
about 725kg
Protection grade
IP54 at the wrist and IP40 at the body
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Six-Axis Product Parameters
ModelBRTIRUS2550A
Range(Arm)J1:±160° J2:±70° J3:-75°/+115°
Range(Wrist)J4:±180° J5:±125° J6:±360°
Max.speed(Arm)J1:84°/s J2:52°/s J3:52°/s
Max.speed(Wrist)J4:245°/s J5:223°/s J6:223°/s
Arm Length2550mm
Loading ability50kg
Repeated positioning accuracy±0.1mm
Power source8.87kVA
WeightAbout 725kg
Application scenariosHandling，Stamping，Injection molding，Grinding，Cutting，Deburring， Gluing，Stacking，Spraying, etc.
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
