BRTIRWD1606A
Precision Engineered Robotic Systems
SIX AXIS SYSTEM DESIGN
“Six axis Industrial Robot for Welding | 6kg Load 1600mm Arm Length”
System Specifications
Control System
HC Control System
Color(General)
red
Loading Ability
6kg
Arm Length
1600mm
Repeated Positioning accuracy
±0.05mm
Weight
about 157.5kg
Protection grade
Ip54,Dust-proof and water-proof
Accessories
teach pendant and electrical box
Power Supply
220V
Mpa
0.5~0.7MPa
Six-Axis Product Parameters
ModelBRTIRWD1606A
Range(Arm)J1:±165° J2:-95°/+70° J3:±80°
Range(Wrist)J4:±155° J5:-130°/+120° J6:±360°
Max.speed(Arm)J1:158°/s J2:143°/s J3:228°/s
Max.speed(Wrist)J4:342°/s J5:300°/s J6:504°/s
Arm Length1600mm
Loading ability6kg
Repeated positioning accuracy±0.05mm
Power source6.11kVA
WeightAbout 157.5kg
Application scenariosHandling，Stamping，Injection molding，Grinding，Cutting，Deburring， Gluing，Stacking，Spraying, etc.
Operating temperature0℃~40℃
Best temperature15℃~25℃
Relative humidity20~80% RH（No condensation）
