BRTN30WSS5PF/FF
Precision Engineered Robotic Systems
I.M.M. ROBOT SYSTEM DESIGN
“I.M.M Robot for 2200T-4000T Injection Molding Machines | BRTN Series Five-Axis Servo Manipulator”
System Specifications
Control System
HC Control System
Color(General)
white
Loading Ability
60kg
Repeated Positioning accuracy
±0.1mm
Recommended I.M.M(Ton)
2200T-4000T
Power Supply
220V
Arm Length
V:<=3000mm
I.M.M. Robot Product Parameters
ModelBRTN30WSS5PF/FF
Recommended I.M.M2200T-4000T
Traverser DrivenAC Servo motor
Model of EOATFour suctions
Two fixtures
Traverse StrokeTraverse total arch length:6meter
Crosswise Stroke<=2500mm
Vertical Stroke<=3000mm
Max.loading60kg
Dry Take Out TimeUndetermined
Dry Cycle TimeUndetermined
Air Consumption(NL/cycle)47
Repeatability±0.1mm
Power source6.11kVA
WeightNonstandard
Application scenariosInjection molding industry
